Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump

Nome da marca: XINYA
Número do modelo: JYB-80-2Q
MOQ: 1
preço: $1,500-2,000
Informações Detalhadas
Lugar de origem:
Jiangsu, China
Fluxo nominal:
10,6 L/min
Pressão nominal:
80MPa
Max Output Pressure:
100mpa
Volume do tanque:
8l
Energia motora:
1.5kW
estrutura:
Bomba de pistão
Fonte de energia:
Hidráulico
Tipo de combustível:
Gasolina
Curso do motor:
curso 4
Tipo de cilindro:
Cilindro único
Estilo de resfriamento:
Refrigerado a ar
Iniciar o sistema:
Pedal de arranque
Deslocamento:
250CC
Sistema de partida:
Recol/chave elétrica Iniciar
Uso:
Óleo
Destacar:

Yamaha gasoline hydraulic pump

,

80Mpa piston pump unit

,

1.6L/min hydraulic crimping tool

Descrição do produto
Yamaha High-Pressure Hydraulic Pump Unit with Piston Pump Structure Gasoline Engine
Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 0 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 1
Yamaha Gasoline Engine Hydraulic Unit
Application

This Yamaha Gasoline Engine Hydraulic Unit provides power for cutting tools, hydraulic compressors, punching machines, and other construction machinery. It is designed for operation in field applications across electric power, railway, rescue, and construction industries.

Yamaha Engine Features
  • Small power Yamaha engine
  • Low vibration and low noise operation
  • Easy to operate with high safety standards
  • Precise machining technique
  • Long machine life
  • Delicate and beautiful appearance design
  • Broader applicable scope
  • Good quality with minimal malfunctions
Specifications
  • Fuel: Gasoline
  • Stroke: 4 stroke
  • Cylinder: Single Cylinder
  • Cooling Style: Air-cooled
  • Start: Kick Start
  • Displacement: 250cc
  • Starting System: Recoil/Electric Key start
Technical Data for Yamaha Gasoline Engine Hydraulic Unit
Product NO. Type NO. Rated Pressure (Mpa) Rated Flow (L/min) Max output pressure (Mpa) Tank Volume (L)
80043 JYB-80-2Q 80 1.6 100 8
Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 2 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 3 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 4 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 5 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 6 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 7 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 8
For Pricing and Quotations

Please provide the following information in your enquiry:

  • Rated Pressure (Mpa)
  • Rated Flow (L/min)
  • Max output pressure (Mpa)
  • Quantity required

We will provide you with a competitive price after confirming these details.

Contact us by phone or email for more information about our products.
